Dahua 5MP Indoor Eyeball Camera with 25m Smart IR Night Vision and CVI / TVI / AHD / CVBS Support

Key Features

📷 High-Resolution 5MP Video

The camera delivers video with a maximum resolution of 2880 × 1620 pixels, helping capture clearer details during live monitoring and playback.

🎥 Up to 25 Frames per Second

It supports 5MP video recording at up to 25 frames per second for clear and smooth surveillance footage.

🌙 Smart IR Night Vision up to 25m

Two built-in infrared illuminators provide night visibility at distances of up to 25 metres. Smart IR helps distribute infrared light evenly and reduce overexposure on nearby objects.

🔍 Fixed-Focal Lens

The camera is supplied with a 3.6mm fixed lens, while a 2.8mm lens option may also be available depending on the product version.

🔄 Four Switchable Video Formats

The video output can be switched between HDCVI, TVI, AHD and CVBS using a DIP switch, providing compatibility with a wide range of DVR and XVR recorders.

☀️ Improved Backlight Performance

BLC, HLC and DWDR help improve image visibility in scenes with bright backgrounds or uneven lighting.

🖼️ Image Noise Reduction

Built-in 2D Noise Reduction helps reduce visual noise and improve image quality in low-light environments.

🌗 Automatic Day and Night Mode

The ICR day and night function automatically switches between colour imaging during the day and black-and-white imaging at night.

🔒 Privacy Masking

The camera supports up to 8 rectangular privacy masking areas for hiding selected parts of the image.

🛠️ Quick and Flexible Installation

Its compact eyeball design allows easy angle adjustment and supports wall, ceiling and vertical pole installation.

Technical Specifications

Camera Type: HDCVI Eyeball Camera

Installation Environment: Indoor

Camera Resolution: 5MP

Maximum Resolution: 2880 × 1620

Image Sensor: 5MP CMOS

Scanning System: Progressive Scan

PAL CVI Frame Rate: Up to 25fps at 5MP, 4MP and 1080p

NTSC CVI Frame Rate: Up to 25fps at 5MP and 30fps at 4MP and 1080p

Supported Resolutions: 5MP, 4MP, 1080p and 960H

PAL Electronic Shutter: 1/25s to 1/100,000s

NTSC Electronic Shutter: 1/30s to 1/100,000s

Lens Type: Fixed-focal

Lens Mount: M12

Standard Lens: 3.6mm

Optional Lens: 2.8mm

Maximum Aperture: F2.0

2.8mm Field of View: Horizontal 105.5°, vertical 56.5°, diagonal 125.3°

3.6mm Field of View: Horizontal 86°, vertical 46.1°, diagonal 104.3°

2.8mm Close Focus Distance: 1m

3.6mm Close Focus Distance: 1.4m

Night Vision Distance: Up to 25m

Illumination Technology: Smart IR

Infrared Illuminators: 2 IR lights

Minimum Colour Illumination: 0.02 Lux

Minimum Black-and-White Illumination: 0.002 Lux

Minimum Illumination with IR On: 0 Lux

Signal-to-Noise Ratio: Greater than 65dB

Day and Night Modes: Auto / Colour / B&W

Backlight Compensation: BLC, HLC and DWDR

Noise Reduction: 2D NR

White Balance: Auto and Area White Balance

Gain Control: Automatic

Mirror Function: Supported

Privacy Masking: Up to 8 rectangular areas

Video Output: CVI / TVI / AHD / CVBS

Video Connector: BNC

Signal Switching: DIP Switch

Power Supply: 12V DC ±30%

Power Consumption: Maximum 2.5W with IR on

Operating Temperature: -40°C to +60°C

Operating Humidity: Less than 95%, non-condensing

Casing Material: Plastic

Product Dimensions: Approximately Φ85 × 77.1mm

Net Weight: Approximately 130g

Gross Weight: Approximately 190g

Installation: Wall, ceiling or vertical pole mounting

This camera is a practical surveillance solution that combines 5MP video quality, 25-metre night vision, quick installation and broad recorder compatibility.
