Dahua 2MP Full HD Indoor Eyeball Camera with Smart IR Night Vision up to 20m, Fixed Lens and CVI / TVI / AHD / CVBS Support

Dahua 2MP Full HD Indoor Eyeball Camera with 20m Smart IR Night Vision, Fixed Lens and CVI / TVI / AHD / CVBS Support

Product Summary

A 2MP Full HD Dahua security camera featuring a fixed lens, Smart IR night vision up to 20 metres and switchable CVI, TVI, AHD and CVBS video output. Its compact eyeball design allows fast installation and flexible angle adjustment, making it suitable for homes, offices, shops and warehouses.

Key Features

📷 Full HD Image Quality

The camera delivers clear video with a maximum resolution of 1920 × 1080 pixels, helping capture important details during live monitoring and playback.

🎥 Up to 30 Frames per Second

It supports 1080p video at up to 30 frames per second, providing smooth and clear video footage.

🌙 Smart IR Night Vision up to 20m

The built-in infrared illuminator provides visibility at distances of up to 20 metres. Smart IR technology automatically adjusts the infrared intensity to reduce overexposure on nearby people and objects.

🔍 Fixed-Focal Lens

The camera is commonly supplied with a 3.6mm fixed lens, while 2.8mm and 6mm lens options may also be available depending on the camera version.

🔄 Four Switchable Video Formats

The video output can be switched between:

- HDCVI

- TVI

- AHD

- CVBS

This provides compatibility with a wide range of DVR and XVR recording systems.

☀️ Improved Backlight Performance

The camera supports DWDR and BLC, helping improve visibility when subjects are positioned in front of bright backgrounds.

🖼️ Noise Reduction

Built-in 2D Noise Reduction helps reduce image noise and improve video quality in low-light environments.

🌗 Automatic Day and Night Mode

The automatic ICR day and night function provides natural colour images during the day and clearer black-and-white images at night.

🛠️ Easy-to-Install Design

The compact eyeball design allows flexible angle adjustment and supports both wall and ceiling installation.

Technical Specifications

- Camera type: HDCVI Eyeball Camera

- Camera resolution: 2MP

- Maximum resolution: 1920 × 1080

- Image sensor: 2MP CMOS

- Scanning system: Progressive Scan

- Frame rate: Up to 30fps at 1080p

- Lens type: Fixed-focal

- Standard lens: 3.6mm

- Maximum aperture: F2.0

- 2.8mm horizontal field of view: 100°

- 6mm horizontal field of view: 43°

- Night vision distance: Up to 20m

- Illumination mode: Smart IR

- Infrared illuminators: 1 IR light

- Minimum colour illumination: 0.02 Lux

- Minimum black-and-white illumination: 0.002 Lux

- Minimum illumination with IR on: 0 Lux

- Backlight compensation: BLC and DWDR

- Noise reduction: 2D NR

- White balance: Automatic

- Gain control: Automatic

- Day and night modes: Auto / Colour / B&W

- Video output: CVI / TVI / AHD / CVBS

- Video connector: BNC

- Power supply: 12V DC ±30%

- Power consumption: Maximum 2.3W

- Operating temperature: -40°C to +60°C

- Operating humidity: Less than 95%, non-condensing

- Casing material: Plastic

- Product dimensions: Approximately 85.4 × 68.8mm

- Net weight: Approximately 90g

- Installation: Wall or ceiling mounting

This camera is a practical and cost-effective choice for residential and commercial surveillance systems, combining Full HD video, reliable night vision, easy installation and wide recorder compatibility.
