Dahua 5MP Outdoor Bullet Camera with 20m Smart IR Night Vision and CVI / TVI / AHD / CVBS Support

Key Features

📷 High-Resolution 5MP Video

The camera delivers video with a maximum resolution of 2880 × 1620 pixels in a 16:9 aspect ratio, helping capture clear details during live monitoring and playback.

🎥 Up to 25 Frames per Second

It supports 5MP video recording at up to 25 frames per second for clear and smooth surveillance footage.

🌙 Smart IR Night Vision up to 20m

The built-in infrared illumination provides night visibility at distances of up to 20 metres. Smart IR technology helps adjust the infrared intensity and reduce overexposure on nearby objects.

🔍 Fixed-Focal Lens

The camera is commonly supplied with a 3.6mm fixed lens, while a 2.8mm lens option may also be available depending on the product version.

🔄 Four Switchable Video Formats

The camera supports switchable HDCVI, TVI, AHD and CVBS video output, providing compatibility with a wide range of DVR and XVR recorders.

☀️ Improved Backlight Performance

BLC, HLC and DWDR technologies help improve image visibility in scenes with strong backlighting or uneven illumination.

🖼️ Image Noise Reduction

Built-in 2D Noise Reduction helps reduce visual noise and improve video quality in low-light environments.

🌗 Automatic Day and Night Mode

The ICR day and night function automatically switches between colour imaging during the day and black-and-white imaging at night.

🔒 Privacy Masking

The camera supports up to 8 rectangular privacy masking areas for hiding selected parts of the image.

🌧️ Weather-Resistant Design

Its IP67 protection rating provides resistance against dust and water, making the camera suitable for outdoor installation.

🛠️ Flexible Installation

The compact bullet design supports wall and ceiling mounting with flexible viewing-angle adjustment.

Technical Specifications

Camera Type: HDCVI Bullet Camera

Installation Environment: Indoor and outdoor

Camera Resolution: 5MP

Maximum Resolution: 2880 × 1620

Image Sensor: 1/2.7-inch CMOS

Scanning System: Progressive Scan

PAL Frame Rate: Up to 25fps at 5MP, 4MP and 1080p

NTSC Frame Rate: Up to 25fps at 5MP and up to 30fps at 4MP and 1080p

Supported Resolutions: 5MP, 4MP, 1080p and 960H

PAL Electronic Shutter: 1/25s to 1/100,000s

NTSC Electronic Shutter: 1/30s to 1/100,000s

Lens Type: Fixed-focal

Lens Mount: M12

Standard Lens: 3.6mm

Optional Lens: 2.8mm

Maximum Aperture: F2.0

2.8mm Field of View: Horizontal 106°, vertical 56°, diagonal 125°

3.6mm Field of View: Horizontal 88°, vertical 46°, diagonal 104°

2.8mm Close Focus Distance: 0.8m

3.6mm Close Focus Distance: 1.2m

Night Vision Distance: Up to 20m

Illumination Technology: Smart IR

Minimum Colour Illumination: 0.02 Lux at F2.0

Minimum Illumination with IR On: 0 Lux

Signal-to-Noise Ratio: Greater than 65dB

Day and Night Modes: Auto ICR / Colour / B&W

Backlight Compensation: BLC, HLC and DWDR

Noise Reduction: 2D NR

White Balance: Automatic and manual

Gain Control: AGC

Mirror Function: Supported

Privacy Masking: Up to 8 rectangular areas

Video Output: CVI / TVI / AHD / CVBS

Video Connector: BNC

Audio: Not supported

Power Supply: 12V DC ±30%

Power Consumption: Maximum 3.7W with IR on

Protection Rating: IP67

Operating Temperature: -40°C to +60°C

Operating Humidity: Less than 95%, non-condensing

Casing Material: Plastic

Product Dimensions: Approximately 149.3 × 69.8 × 69.8mm

Net Weight: Approximately 150g

Gross Weight: Approximately 250g

Installation: Wall or ceiling mounting

This camera is a practical and cost-effective outdoor surveillance solution that combines 5MP video quality, Smart IR night vision, weather resistance and broad recorder compatibility.
